Bitzer Medium ad Maximum Temperature Piston Parallel Unit
Bitzer medium ad piston caliditatis parallelae unitatis lineas parallelas conformationem plurium pistonium compressorum, permittens operationem flexibilem secundum realem tempus postulata refrigerationis oneris. Hoc ridiculo vel coniuncto operandi accessus efficit ut systema efficientem et constantem refrigerationem per varias condiciones defendat, eamque idoneam ad frigidum reponendi commercialem, cibi processus facultates, et systemata refrigerandi industriae ubi certa temperaturae moderatio critica est.
Instructus completo numero elementorum essentialium, unitas receptaculum liquidum, oleum separator, oleum receptaculum, valvulas reprimendam, oleum coaequantem et vibrationem fistulas hauriendi includit. Haec elementa efficiunt etiam distributionem refrigerandi et lubricandi oleum inter compressores, operationem coordinatam augentes et altiorem systematis paralleli efficientiam. Inclusio pressionis moderatoris et scrinium electricum moderamen praebet centralizatum vigilantiam et accuratam potestatem in parametri systematis, in melius operationis salutem et responsionem ad mutanda onera. Accedit modulus, compages compages simpliciores institutionem, sustentationem, ac futuram expansionem simpliciorem praebens, altam aptabilitatem pro diversis situs requisitis praebens.
Unitas etiam cochleae semi-hermeticae compressores e notis domesticis et internationalibus notis incorporat, ut altam efficientiam operationalem, vitam servitutis extensam, tremorem minimam, et sonum humilem camporum. Bitzer mediae caliditatis anconis parallelae unitatis cum sua certa componentium delectu ac robusto consilio, unum praebet altum operandi, solutionem energiae efficacem pro amplis applicationibus refrigerationis, componendo qualitatem, durabilitatem et stabilitatem perficiendam..
Introductio Parametrorum Machinae
Ostensio Singularum
Nobiscum Communica
Introductio Parametrorum Machinae
| Unitas Model | Cam.Model | Com. Cuartity | Condensing temp. (℃) | Evaporatio Nativ. (℃) | Alveus (L) | Supply tibia (mm) | Suctionisis tibia (mm) | Gas Outiet tibia (mm) | liquid inlettibia (mm) | Dimensio (mm) (L×W×H) | |||||||||
| -20 | -25 | -30 | -35 | -40 | |||||||||||||||
| Refrigerium Capacity/Power lnput(kw) | |||||||||||||||||||
| LXPL-BBF2 -20M | 4VES-10 (10HP) | 2 | 35 | 31.5 | 11.0 | 39.3 | 12.0 | 48.0 | 12.7 | 58.8 | 13.3 | 70.8 | 13.7 | 40 | Φ22 | Φ42 | Φ35 | Φ28 | 2550×1200×1850 |
| 40 | 29.4 | 11.6 | 36.8 | 12.7 | 45.4 | 13.6 | 55.4 | 14.4 | 67.0 | 15.0 | |||||||||
| 45 | 27.2 | 10.2 | 34.4 | 13.3 | 42.6 | 14.4 | 52.2 | 15.4 | 63.0 | 16.2 | |||||||||
| LXPL-BBF2 -30M | 3 | 35 | 47.3 | 16.5 | 59.0 | 17.9 | 72.6 | 19.1 | 88.2 | 20.0 | 106.2 | 20.6 | 60 | Φ22 | Φ54 | Φ42 | Φ28 | 3150×1000×1850 | |
| 40 | 44.1 | 17.3 | 55.3 | 19.0 | 68.1 | 20.4 | 83.1 | 21.6 | 100.5 | 22.5 | |||||||||
| 45 | 40.9 | 18.1 | 51.5 | 20.0 | 63.9 | 21.6 | 78.3 | 23.1 | 94.5 | 24.3 | |||||||||
| LXPL-BB2 -40M | 4 | 35 | 63.0 | 22.0 | 78.8 | 23.9 | 96.8 | 25.5 | 117.6 | 26.6 | 141.6 | 27.4 | 60 | Φ28 | Φ54 | Φ42 | Φ35 | 3800×1000×1850 | |
| 40 | 58.8 | 23.1 | 73.7 | 25.3 | 90.8 | 27.2 | 110.8 | 28.8 | 134.0 | 30.0 | |||||||||
| 45 | 54.5 | 24.1 | 68.7 | 26.6 | 85.2 | 28.8 | 104.4 | 30.8 | 126.0 | 32.4 | |||||||||
| LXPL-BBF2 -30M | 4PES-15 (15HP) | 2 | 35 | 43.6 | 15.2 | 54.4 | 16.6 | 67.0 | 17.8 | 81.6 | 18.6 | 98.2 | 19.2 | 60 | Φ22 | Φ54 | Φ35 | Φ28 | 2550×1200×1850 |
| 40 | 40.4 | 16.0 | 50.8 | 17.8 | 63.0 | 19.0 | 75.8 | 20.1 | 92.8 | 21.0 | |||||||||
| 45 | 37.5 | 16.6 | 47.4 | 18.5 | 58.8 | 20.1 | 72.2 | 21.5 | 87.4 | 22.7 | |||||||||
| LXPL-BBF2 -45M | 3 | 35 | 65.4 | 22.8 | 81.6 | 24.9 | 100.5 | 26.6 | 122.4 | 27.9 | 147.3 | 28.7 | 60 | Φ28 | Φ76 | Φ54 | Φ35 | 3150×1000×1850 | |
| 40 | 60.6 | 24.0 | 76.2 | 26.4 | 94.5 | 28.5 | 115.2 | 30.2 | 139.2 | 31.4 | |||||||||
| 45 | 56.2 | 25.0 | 71.1 | 27.7 | 88.2 | 30.2 | 108.3 | 32.3 | 131.1 | 34.0 | |||||||||
| LXPL-BBF2 -60M | 4 | 35 | 87.2 | 30.4 | 108.8 | 33.2 | 34.0 | 35.5 | 163.2 | 37.2 | 196.4 | 38.8 | 100 | Φ35 | Φ89 | Φ54 | Φ42 | 3800×1000×1850 | |
| 40 | 80.8 | 32.0 | 101.6 | 35.2 | 126.0 | 38.0 | 153.6 | 40.2 | 185.6 | 41.9 | |||||||||
| 45 | 74.9 | 33.3 | 94.8 | 36.9 | 117.6 | 40.2 | 144.4 | 43.0 | 174.8 | 45.3 | |||||||||
| LXPL-BBF2 -40M | 4NES-20 (20HP) | 2 | 35 | 51.4 | 18.0 | 64.2 | 19.5 | 78.8 | 20.8 | 95.6 | 21.7 | 115.2 | 22.3 | 60 | Φ28 | Φ54 | Φ42 | Φ35 | 3200×1950×1700 |
| 40 | 48.0 | 18.9 | 60.2 | 20.7 | 74.2 | 22.2 | 90.4 | 23.5 | 108.8 | 24.5 | |||||||||
| 45 | 44.6 | 19.7 | 56.2 | 21.8 | 69.6 | 23.6 | 85.0 | 25.2 | 102.6 | 26.5 | |||||||||
| LXPL-BBF2 -60M | 3 | 35 | 77.1 | 27.0 | 96.3 | 29.3 | 118.2 | 31.1 | 143.4 | 32.6 | 172.8 | 33.5 | 100 | Φ35 | Φ76 | Φ54 | Φ42 | 4100×1950×1750 | |
| 40 | 72.0 | 28.4 | 90.3 | 31.0 | 111.3 | 33.4 | 135.6 | 35.3 | 163.2 | 36.7 | |||||||||
| 45 | 66.9 | 29.6 | 84.3 | 32.6 | 104.4 | 35.4 | 127.5 | 37.8 | 153.9 | 39.7 | |||||||||
| LXPL-BBF2 -80M | 4 | 35 | 102.8 | 36.0 | 128.4 | 39.0 | 157.6 | 41.5 | 191.2 | 43.4 | 230.4 | 44.6 | 100 | Φ35 | Φ89 | Φ54 | Φ42 | 4950×1950×1800 | |
| 40 | 96.0 | 37.8 | 120.4 | 41.4 | 148.4 | 445. | 180.8 | 47.0 | 217.6 | 48.9 | |||||||||
| 45 | 89.2 | 39.4 | 112.4 | 43.5 | 139.2 | 47.2 | 170.0 | 50.4 | 205.2 | 53.0 | |||||||||
| LXPL-BBF2 -50M | 4HE-25 (25HP) | 2 | 35 | 68.8 | 24.2 | 85.4 | 26.1 | 104.6 | 27.7 | 126.8 | 29.0 | 152.2 | 29.7 | 100 | Φ28 | Φ76 | Φ54 | Φ35 | 3200×1950×1700 |
| 40 | 64.4 | 25.5 | 80.4 | 27.8 | 98.8 | 29.8 | 120.0 | 31.4 | 144.2 | 32.6 | |||||||||
| 45 | 60.0 | 26.7 | 75.2 | 29.3 | 92.8 | 31.7 | 113.0 | 33.8 | 136.2 | 35.4 | |||||||||
| LXPL-BBF2 -75M | 3 | 35 | 103.2 | 36.2 | 128.1 | 39.2 | 156.9 | 41.6 | 190.2 | 43.4 | 228.3 | 44.6 | 100 | Φ35 | Φ89 | Φ54 | Φ42 | 4100×1950×1750 | |
| 40 | 96.6 | 38.2 | 120.6 | 41.6 | 148.2 | 44.7 | 180.0 | 47.1 | 216.3 | 48.9 | |||||||||
| 45 | 90.0 | 40.0 | 112.8 | 44.0 | 139.2 | 47.6 | 169.5 | 50.7 | 204.3 | 53.1 | |||||||||
| LXPL-BBF2 -100M | 4 | 35 | 137.6 | 48.3 | 170.8 | 52.2 | 209.2 | 55.5 | 253.6 | 57.9 | 304.4 | 59.4 | 150 | Φ42 | Φ89 | Φ67 | Φ54 | 4950×1950×1800 | |
| 40 | 128.8 | 50.9 | 160.8 | 55.5 | 197.6 | 59.6 | 240.0 | 62.8 | 288.4 | 65.2 | |||||||||
| 45 | 120.0 | 53.3 | 150.4 | 58.6 | 185.6 | 63.4 | 226.0 | 67.6 | 272.4 | 70.8 | |||||||||
| Unitas Model | Com.Model | Com. Cuartity | Condensing temp. (℃） | Evaporatio Nativ. (℃) | Alveus (L) | Supply tibia (mm) | Suctionisis tibia (mm) | Gas Outiet tibia (mm) | liquid inlettibia (mm) | Dimensio (mm) (L×W×H) | |||||||||
| -20 | -25 | -30 | -35 | -40 | |||||||||||||||
| Capacitas refrigerium / Input Power (kw) | |||||||||||||||||||
| LXPL-BBF2 -60M | 4GE-30 (30HP) | 2 | 35 | 80.0 | 27.9 | 99.0 | 30.1 | 121.2 | 31.9 | 144.6 | 33.3 | 176.0 | 34.1 | 100 | Φ35 | Φ76 | Φ54 | Φ42 | 2550×1200×1850 |
| 40 | 75.0 | 29.4 | 93.2 | 32.0 | 114.4 | 34.3 | 138.8 | 36.1 | 166.8 | 37.5 | |||||||||
| 45 | 70.0 | 30.9 | 87.4 | 33.9 | 107.6 | 36.6 | 131.0 | 38.9 | 157.6 | 40.8 | |||||||||
| LXPL-BBF2 -90M | 3 | 35 | 120.0 | 41.8 | 148.5 | 45.1 | 181.8 | 47.8 | 219.9 | 49.9 | 264.0 | 51.1 | 100 | Φ35 | Φ89 | Φ54 | Φ42 | 3150×1000×1850 | |
| 40 | 112.5 | 44.1 | 139.8 | 48.0 | 171.6 | 51.4 | 208.2 | 54.2 | 250.2 | 56.2 | |||||||||
| 45 | 105.0 | 46.3 | 131.1 | 50.8 | 161.4 | 54.8 | 196.5 | 58.3 | 236.4 | 61.2 | |||||||||
| LXPL-BB2 -120M | 4 | 35 | 160.0 | 55.7 | 198.0 | 60.1 | 242.4 | 63.8 | 293.2 | 66.5 | 352.0 | 68.2 | 150 | Φ42 | Φ108 | Φ55 | Φ54 | 3800×1000×1850 | |
| 40 | 150.0 | 58.8 | 186.4 | 64.0 | 228.8 | 68.6 | 277.6 | 72.2 | 333.6 | 74.9 | |||||||||
| 45 | 140.0 | 61.8 | 174.8 | 67.7 | 215.2 | 73.1 | 262.0 | 77.8 | 315.2 | 81.6 | |||||||||
| LXPL-BBF2 -70M | 4HE-35 (35HP) | 2 | 35 | 103.2 | 36.3 | 128.2 | 39.2 | 157.0 | 41.8 | 190.2 | 43.6 | 228.4 | 44.8 | 100 | Φ35 | Φ89 | Φ54 | Φ42 | 2500×1200×1850 |
| 40 | 96.6 | 38.2 | 120.4 | 41.8 | 148.0 | 44.8 | 179.8 | 47.4 | 216.4 | 49.2 | |||||||||
| 45 | 90.0 | 40.0 | 112.8 | 44.2 | 139.2 | 47.8 | 169.4 | 51.0 | 204.4 | 53.6 | |||||||||
| LXPL-BBF2 -105M | 3 | 35 | 154.8 | 54.4 | 192.3 | 58.9 | 235.5 | 62.7 | 285.3 | 65.4 | 342.6 | 67.2 | 150 | Φ42 | Φ108 | Φ66 | Φ54 | 3150×1000×1850 | |
| 40 | 144.9 | 57.4 | 180.6 | 62.7 | 222.0 | 67.2 | 269.7 | 71.1 | 324.6 | 73.8 | |||||||||
| 45 | 135.0 | 60.0 | 159.2 | 66.3 | 208.8 | 71.7 | 254.1 | 76.5 | 306.6 | 80.4 | |||||||||
| LXPL-BBF2 -140M | 4 | 35 | 205.4 | 72.5 | 256.4 | 78.5 | 314.0 | 83.6 | 380.4 | 87.2 | 456.8 | 89.8 | 200 | Φ54 | Φ108 | Φ79 | Φ66 | 3800×1000×2000 | |
| 40 | 193.2 | 76.5 | 240.8 | 83.6 | 295.0 | 89.6 | 359.6 | 94.8 | 432.8 | 98.4 | |||||||||
| 45 | 180.0 | 80.0 | 225.6 | 88.4 | 278.4 | 95.6 | 338.8 | 102.0 | 408.8 | 107.2 | |||||||||
| LXPL-BBF2 -80M | 4GE-40 (40HP) | 2 | 35 | 118.4 | 41.8 | 147.2 | 45.2 | 180.2 | 48.0 | 218.4 | 50.0 | 262.2 | 51.4 | 100 | Φ35 | Φ89 | Φ54 | Φ42 | 2550×1200×1850 |
| 40 | 110.8 | 44.0 | 138.2 | 48.0 | 170.0 | 51.4 | 206.4 | 54.4 | 284.8 | 56.4 | |||||||||
| 45 | 103.2 | 45.2 | 129.4 | 50.6 | 159.6 | 54.8 | 194.6 | 58.4 | 234.6 | 61.2 | |||||||||
| LXPL-BBF2 -120M | 3 | 35 | 177.6 | 62.7 | 220.8 | 67.8 | 270.3 | 72.0 | 327.6 | 75.0 | 393.3 | 77.1 | 150 | Φ42 | Φ108 | Φ66 | Φ54 | 3150×1000×2000 | |
| 40 | 166.2 | 66.0 | 207.3 | 72.0 | 255.0 | 77.1 | 309.6 | 81.6 | 372.6 | 84.6 | |||||||||
| 45 | 155.1 | 69.3 | 194.1 | 75.9 | 239.4 | 82.2 | 291.9 | 87.6 | 351.9 | 91.8 | |||||||||
| LXPL-BBF2 -160M | 4 | 35 | 236.8 | 83.6 | 294.4 | 90.4 | 360.4 | 96.0 | 436.8 | 100.0 | 524.4 | 102.8 | 200 | Φ54 | Φ108 | Φ79 | Φ66 | 3800×1000×2000 | |
| 40 | 221.6 | 88.0 | 276.4 | 96.0 | 340.0 | 102.8 | 412.8 | 108.8 | 496.8 | 112.8 | |||||||||
| 45 | 206.8 | 92.4 | 258.8 | 101.2 | 319.2 | 109.6 | 389.2 | 116.8 | 469.2 | 122.4 | |||||||||
| LXPL-BBF2 -100M | 4FE-50 (50HP) | 2 | 35 | 142.8 | 51.0 | 177.2 | 55.0 | 216.8 | 58.2 | 262.4 | 60.8 | 314.8 | 62.2 | 150 | Φ42 | Φ89 | Φ76 | Φ54 | 2550×1200×1850 |
| 40 | 133.8 | 53.8 | 166.6 | 58.4 | 204.6 | 62.6 | 248.4 | 65.8 | 298.4 | 68.2 | |||||||||
| 45 | 125.0 | 56.4 | 156.2 | 61.8 | 192.4 | 66.6 | 234.2 | 70.8 | 282.0 | 74.0 | |||||||||
| LXPL-BBF2 -150M | 3 | 35 | 214.2 | 76.5 | 2658 | 82.5 | 325.2 | 87.3 | 3936 | 91.2 | 4722 | 93.3 | 100 | Φ54 | Φ108 | Φ76 | Φ66 | 3150×1000×2000 | |
| 40 | 200.7 | 80.7 | 249.9 | 87.6 | 306.9 | 93.9 | 372.6 | 98.7 | 447.6 | 102.3 | |||||||||
| 45 | 187.5 | 84.6 | 234.3 | 92.7 | 288.5 | 99.9 | 351.3 | 106.2 | 423.0 | 111.0 | |||||||||
| LXPL-BBF2 -200M | 4 | 35 | 285.6 | 102.0 | 354.4 | 110.0 | 433.6 | 116.4 | 524.8 | 121.6 | 629.6 | 124.4 | 250 | Φ54 | Φ133 | Φ108 | Φ66 | 3800×1000×2000 | |
| 40 | 267.6 | 107.6 | 3332 | 116.8 | 409.2 | 125.2 | 496.8 | 131.6 | 596.8 | 136.4 | |||||||||
| 45 | 250.0 | 112.8 | 312.4 | 123.6 | 384.8 | 133.2 | 468.4 | 141.6 | 564.0 | 148.0 | |||||||||
